Flash Codes List and DTCs
P0087 (flash code 227) fuel rail pressure is too low (for a pump without pressure applied)
Main symptoms
• Strong engine vibration.
• Unstable idling
• Output power drop
Exhaust smoke
• There may be too much smoke.
P0088 (flash code 118) fuel rail pressure too high
Main symptoms
• Strong engine vibration
• idle unstable
• Output power drop
• failure to pump the gas engine
Exhaust smoke
• May be too big a way out.
P0089 (flash code 151) fuel rail pressure regulator faulty
Main symptoms
• Strong engine vibration
• idle unstable
• Output power drop
Exhaust smoke
• May be too big a way out.
P0090 (flash code 247) SCV open or short of fuel pressure regulator
Main symptoms
• Depending on the open / short situations, the engine may stop and / or start
Exhaust smoke
• Smoke output too large
P0107 (flash code 71) Atmospheric pressure sensor input signal low (opened or shorted to ground)
Main symptoms
Due to a spare equivalent height of 2000 m (6562 ft)
• exhaust smoke at high altitude.
• low power at low altitude
P0108 (flash code 71) Atmospheric pressure sensor input high (+ 5 V short-circuited)
Main symptoms
Due to a spare equivalent height of 2000 m (6562 ft)
• High exhaust smoke
• lack of power at low altitude
P0112 (flash code 22) intake air temperature sensor malfunction (low voltage error, ground fault, short circuit)
Main symptoms
• Cold start may emit white smoke.
P0113 (flash code 22) intake air temperature sensor fault (high supply voltage circuit fault)
Main symptoms
• Cold start may emit white smoke.
P0117 (flash code 23) engine coolant temperature sensor malfunction (low voltage error, ground fault, short circuit)
Main symptoms
• At normal temperature: smoke may be emitted,
• When the ambient temperature is low when idling: unstable idle may be, engine start is difficult
P0118 (flash code 23) The engine coolant temperature sensor provides overestimated data (closed to positive or short circuit)
Main symptoms
• At normal temperature: smoke may be emitted,
• At low temperatures during idle time: there may be an unstable idle,
P0182 (flash code 211) Malfunctioning fuel temperature sensor (low voltage faults shorted to ground)
Main symptoms
Impact on performance.
P0183 (flash code 211) Malfunctioning fuel temperature sensor (high voltage failure, power circuit open or
short circuit)
P0192 (flash code 245) fuel pressure sensor (low voltage or short circuit)
Main symptoms
• Perhaps stopping the engine
• reduced output power
P0193 (flash code 245) high signal of the fuel pressure sensor (open circuit or short to positive)
Main symptoms
• engine can stop
• Output power drop
P0201 (flash code 271) open circuit of the injector 1 cylinder control
Main symptoms
• strong engine vibration
• Unstable idling
• Output power lowered.
P0202 (flash code 272) open circuit control injector 2 cylinder
Main symptoms
• strong engine vibration
• Unstable idling
• Output power lowered.
• engine failure
P0203 (flashing code 273) interruption of the injector control circuit 3 cylinders
Main symptoms
• strong engine vibration
• Unstable idling
• Output power
• failure to pump the gas engine
P0204 (flash code 274) open circuit of the injector 4 cylinder control
Main symptoms
• strong engine vibration
• Unstable idling
• Output power lowered.
• engine failure
P0205 (flash code 275) open injector control circuit of the 5th cylinder
Main symptoms
• strong engine vibration
• Unstable idling
• Output power lowered.
• Engine failure
P0206 (flash code 276) open circuit of the nozzle control circuit of the 6th cylinder
Main symptoms
• strong engine vibration
• Unstable idling
• Output power underestimated
• Engine failure
P0219 (flash code 543) engine overspeed
Main symptoms
Output power drop
P0237 (flash code 32) failure of the boost pressure sensor (low voltage error, open circuit)
Main symptoms
smoke
P0238 (flash code 32) failure of the boost pressure sensor (high voltage failure, short to negative)
P0335 (flash code 15) crankshaft sensor malfunction (no signal)
Main symptoms
• Output drop underestimated
• exhaust white smoke
• Motor vibration can be severe.
• engine may stop
P0336 (flash code 15) crankshaft sensor malfunction (signal failure)
Main symptoms
• Output drop low
• exhaust white smoke
• Motor vibration can be severe.
• The engine may stop (when the camshaft position sensor is normalized, it may start up again.
